Hightest - Model TRIORES-20 Series - Three-phase Winding Resistance Tester with Printer

TRIORES-20 Series is designed using advanced engineering technology to measure the winding resistance of transformers.
TRIORES-20 Series can measure current, voltage, power transformer windings and shunt resistors.
Applying up to 20A Direct Current allows TRIORES-20 Series to measure the resistance of the transformers fast and accurate.
The smart design of the TRIORES-20 Series makes it easier to determine the end of measurement automatically according to users’ decisions.
TRIORES-20’s measurement channels are designed in such a way that it can measure both three-phase and single-phase transformers’ winding resistance. Users need to connect the test cables just one time to measure all three phases while testing three-phase transformers.
Beginning from 0.1 μΩ resistances, TRIORES-20 Series can measure up to 100,000 Ω resistance. TRIORES-20 Series discharges the measured circuit after each test.
Dynamic resistance (OLTC) control of on-load tap changers, which can be performed simultaneously on all three phases, or a single phase.
For inductive load, TRIORES-20 Series can demagnetise the load. The temperature measurement input enables one to connect an optional sensor to TRIORES-20 Series and perform temperature correction automatically.

TRIORES-20 Series’s intelligent software allows controlling the current flow if there is a failure in the current circuit. With this feature, TRIORES-20 Series procures added safety to users.

A 7-inch TFT touch display allows TRIORES-20 Series to show all measurement results on a single screen. TRIORES-20 Series can be controlled by USB and optional Bluetooth interface and users can record/store measurement results. In case setting up a Laptop or PC for the field test is difficult; users can record data to the device’s internal memory (up to 100 Test Records) or to an external USB flash memory.

With the HighTest Data Management Platform (DMP Software), users can control TRIORES-20 Series, analyse and manage measurement results using a PC. Operators can easily print the measurement results with the 2.28-inch built-in Printer of the TRIORES-20 Series.

TRIORES-20 Series has an optional battery power feature that allows users to make tests even when there is no electricity. Multi-language capability and user-friendly operation menu make it easy to control TRIORES-20 Series, even by less trained staff.

TRIORES-20 Series can control tap changer (raise and lower) with its tap changer outputs. TRIORES-20 Series is a light, compact and rugged device with the protection class IP67 (case closed).

• Fully Automatic Three-phase and single-phase resistance measurement
• Simultaneous primary & secondary measurement without disconnecting and reconnecting cables
• Measurements from 0.1 μΩ to 100,000 Ω
• 0.001 A to 20 A DC adjustable current output
• High accuracy (0.1%)
• Test Voltage 50 V
• Demagnetisation feature
• Dynamic resistance (OLTC) measurement
• Built-in printer
• Optional Battery
• Internal memory, USB Flash Drive
• PC control via USB cable
• Optional Bluetooth control and communication
• 7-inch large colour touch display
• Temperature correction (1 input, sensor optional)
• User-friendly operation menu
• Data Management Platform (DMP Software) allows to control TRIORES-20, analyse and manage results on PC

• Measurement Parameters : Three-phase and single-phase resistance measurement
• Test Voltage : 50 V (Continuous)
• Current output : From 0.001 A to 20 A DC (User-selectable)
• Resistance Measurement : From 0.1 μΩ to 100,000 Ω
• Accuracy : 0.1%
• Resolution : 5 digits
• Demagnetisation : Yes
• Power Supply : 100 – 240 V, 47/63 Hz
• Battery : 14.4 V 6.9 Ah battery (Optional) (Models: TRIORES-20B, TRIORES-20B BLUE)
• Memory    : Up to 100 records (include up to 25 tap results), Unlimited Storage using an external USB
• Printer : 2.28-inch built-in Printer
• Communication : USB 2.0/1.1 Standard-A, USB 2.0/1.1 Standard-B, Optional Bluetooth(Models: TRIORES-20 BLUE, TRIORES-20B BLUE)
• PC Software : DMP Software
• Display : 7-inch Colour Touch Display
• Dimensions : 16.7″ x 13.4″ x 6.8″  (424 mm x 340 mm x 173 mm )
• Weight : 7 kg (models with battery)
• Working Temperature : -10 °C to +60 °C
• Storage Temperature : -30 °C to +70 °C
• Humidity : 95% RH Non-condensing
• Protection Class : IP67 (case closed)
• Set of Package : TRIORES-20, Power Cable, Ground Cable, 1 x 5 m (16.4 ft.) Current Cable Set, 2 x 5 m (16.4 ft.) Voltage Cable Set, USB Cable, Tap Changer Cable Set, Jumper Cable, Printer Paper (x2), USB flash drive, Instruction Manual (Soft Copy), DMP Software, Cable Bag
• Options : Hard carrying case, Battery, Bluetooth (factory install), Temperature Sensor
• Ordering Information : TRIORES-20, 20A Winding Resistance Tester with Built-in Printer
• TRIORES-20 BLUE, 20A Winding Resistance Tester with Built-in Bluetooth & Printer
• TRIORES-20B, 20A Winding Resistance Tester with Built-in Battery & Printer
• TRIORES-20B BLUE, 20A Winding Resistance Tester with Built-in Battery, Bluetooth & Printer
