Tilt Single Axis Solar Tracking System
From Solar Sun Tracker
With Linkage structure, one motor powers the whole system with many standalone solar units, greatly reducing the operating costs; can be flexibly installed on sloped or uneven areas with little impacts upon the motor driving and system operation due to the Multilateration technology. Use high-grade Steel Q235 for main mounting structures of the system. With oil hole in the rotating machine, the tracking system can be easily maintained during the operation. With high-accuracy solar position algorithm, the tracking sensor catch the sun ray automatically without any manual intervention and debugging; excellent adaptability to the installation environment and the weather. All structure components are hot-dip galvanized with 25years service life.
-
Most popular related searches
Features
- Rotatable Drive of Four-linkage; Slewing Supporting Drive;
- Modular assembly; Reverse Tracking Control/ No Shadowing;
- Night-return Function; Soft Start-up and Brake;
- Able to Resist Natural Disasters; Network Monitoring.
Technical Parameters
- Installation Power: Can be customized
- Controlling Method: Time Control/Light& Time Control/Tilt angle adjustment & Time Control
- Tracking Accuracy: ≤0.2°
- Tilt Angle: According to clients’requirements and the installation site
- Azimuth angle: -45°~45°
- Altitude Angle: -20°~90°
- Working Wind Speed: 28m/s
- Maximum Wind Resistance: 42m/s
- Driven power: Rotation motor driving
- Driven Motor: DC: 24V/48V; AC: 220V/380V
- System Power: AC: 220V/380V
- Structural Material: Hot-galvanized steel
- Protection Level: IP65
- Operation Temperature: -40℃~+85℃
- Service/warranty: 10years
