Turbojet Side Burner

SHARE

Turbojet  is a high-speed burner, working with natural gas and GPL. It introduces the combustible gases in the kiln, at a speed measurable around 130 m/sec and therefore offering three main advantages: a uniform distribution of the temperature in the kiln sections, consequence of the turbulence generated by the high speed and the mixing of burning gases with the air around;  an equal heating of every layer of piled material, as well as a uniform heating of the car- coating; a quicker increment of the material temperature, thanks to the high exchange-temperature coefficient, caused by the air speed around it. The burner, equipped with a proper  flame, can work where the temperature results lower than the self-burning level of the combustible (680°C). it can be used, then, both in the pre-heating and in the cooking areas.

Most popular related searches

The burner is composed by:

  • burning-air introduction group made up of solenoid valve for the interception of air, manual valve for regulation;
  • plant for gas-feeding composed by: electro-valve  for minimum level of flame, electro-valve for maximum level of flame;
  • mixing and starting systems;
  • burner structure;
  • burning room in carburo of silicium or in refractory material;
  • housing in stainless-steel.
  • Combustible type: methane
  • Max. potential: Kcal/h 180.000
  • Gas rate: Nmc/h 3,5-21
  • Air rate: Nmc/h 40/300
  • Gas pressure: mBar 200
  • Burning-air pressure: mBar 63
