Concord - Model CRE-960 Bermer -Under Tailgate Hydraulic Driven Cross Conveyor
Stainless steel construction in lieu of painted steel. 12″ back guard extension (Standard is 7″). Stop-Tail-Turn LED & 3-light LED cluster recessed into rear cover. Adjustable material spinner assembly with deflector & 18″ steel or polydisk. 60″ adjustable auger extension. Self-Leveling mounting system, includes upper pivot arms & lower pivot structure. Self-contained portable hydraulic power pack. 48″ fold-up conveyor extension. Manually adjustable discharge door. Folding leg & winch mounting system.
Most popular related searches
- Body Series: CRE-960 SERIES
- Construction: Heavy duty steel (or optional stainless steel) hopper with full length rubber sealing skirts to keep material on top of belt
- Conveyor System: Pure belt conveyor with R2 lacing and pin, rubber lagged drive roller, five individual idler rollers, and one adjustable take up roller
- Drive System: Conveyor belt is driven by a hydraulic motor through chain and sprocket reduction, optional flow control available to allow for speed adjustments
- Bearings: All shafts are supported by greaseable flange mounted bearings on drive and idler rollers with sliding takup bearings to adjust belt tension
- Discharge: Hinged discharge doors on both end of hopper and hydraulic couplers allow for belt to run in either direction
- Material Chute: Unit comes standard with a material chute that can mount on either end of the machine and pivots under machine for transport
- Paint: Standard unit comes epoxy primed and painted safety orange
- Mounting Options: Available self leveling mount to keep machine level through out operating angles or leg and winch mount for easy transfer between vehicles
