Stropuva - Model S10U – 10kw -Universal Boiler
When the firewood is loaded, a single load burns up to about 30 hours. A single load of sawdust briquettes burns up to 4 hours. A single load of pellets burns up to 96 hours. Solid fuel: firewood, timber waste, sawdust, straw and peat briquettes. Combustion duration of solid fuel load depends on its quality of fuel, outdoor and indoor temperature, thermal resistance, and other factors. Recommended moisture ≤30%*
Most popular related searches
wood pellet burning
pellet burning
wood pelletizing
wood pellet
wood pelletting
wood burning
coal burning
peat briquetting
boiler efficiency
- Model: S10 U
- Power (kW)*: 10
- Heating area (m²)**: 50-100
- Fuel capacity (dm³): 135
- Maximum amount of firewood (kg): 25
- Maximum amount of wood pellets (kg): 80
- Maximum amount of briquettes (kg): 30
- Maximum amount of coals(kg): 75
- Wood burning time on minimum mode (hours): 31.5
- On maximum mode ***: 6.1
- Wood pellets burning time on minimum mode (hours): 72
- On maximum mode ***-:
- Briquettes burning time on minimum mode(hours): 96
- On maximum mode ***: 24
- Coal burning time on minimum mode (hours): 130
- on maximum mode ***: 32
- Length of firewood up to (cm): 35
- Amount of water in the boiler (l): 22
- Efficiency (%): 86.8
- Pressure safety valve (bar): 1.5
- Chimney draught (Pa): 10-20
- Flow of heated water (l/h): 250
- Water temperature in the boiler (°C): 85
- Minimal area of chimney flue (cm²): 200
- Chimney diameter (mm): 180
- Distance between boiler bottom and chimney (mm): 1494
- Height (mm): 1900
- Diameter (mm): 450
- Weight (kg): 177
