Sail - Villa Elevator

Non-well Solution Plan For Villa Lift
While installing villa elevator near the corridor or outside the villa, bent forming steel frame and steel frame out of aluminum alloy section  material are your first-choices in quickly building up elevator well . While installing villa elevator near the corridor or outside the villa, bent forming steel frame and steel frame out of aluminum alloy section  material are your first-choices in quickly building up elevator well . According to house structure  door-opening  requirements, backpack frame style or portal frame style small house lifts/elevator structure for  your choice. VVVF drive technology special-purpose micro-computer panel control, smooth and comfortable. Steel structure well frame, it is of high cost performance. N Later outer plating will be packaged by decoration unit. Home passenger lifts coincides with design style. Free selection of installation position. Surface painted&  anti-rusting  treatment,  anti-corrosive. Aluminum  alloy  well frame, elegant  and  attractive  independent  framework  glass design, No extra building cost. This small house lifts integrates with indoor decoration into one with fine transmission of light. Free selection of installation position. Anti-corrosive long life cycle. Household lifts always choose industrial level aluminum alloy. Glass applies 5+ 5mm thickness safety laminated glass.

Steel Belt Villa Elevator / Household Lifts

Steel band traction technolology has been controlled by foreign-invested elevator factories.  Following such technological break-through, the company leaders firstly grasp this business opportunity. Household elevator lays importance upon researching into, developing and quickly putting out the first set of steel band traction type villa elevator. Steel band applies special material package. Steel wire is not rusty. It does not wear the traction sheave and don`t need lubricating oil. It is maintenance-free with the longer life, large frictional coefficient, the more powerful traction capacity.  Household lifts can be 20%lighter.  It reduces energy consumption.  Compact permanent magnet synchronous and gear-less traction machine, small axis diameter traction sheave, diversion sheave, counterweight sheave bring about the smaller well projection area. It can save 15% of well area.  Meanwhile, small house lifts greatly reduce top-floor and pit space.

Traction Type Villa Elevator or Household Lifts

According to house structure  door-opening  requirements, backpack frame style or portal frame style elevator structure for  your choice. VVVF drive technology special-purpose micro-computer panel control, smooth and comfortable. Special purpose  traction machine is fixed in guide rail. Building does not bear any load. Host: It applies 220V~ 380V single-phase power supply, ordinary home-use power. It needs no additional application of industrial power. Automatic door machine: Variable frequency energy-saving safe  and  reliable. UPS (spare power)  can emergency release passengers at power failure. One-key dialing telephone makes roll call to 3-5main  family members at emergency conditions. Total rated power 1.5KW in operation (including 1.1KW drive system). Power is less than a micro-wave oven. It saves8O%  power  compared  with  small  commercial elevator. Intellectual service: It links with owners mobilethrough network. It executes real-time monitor to elevator running conditions.

SA-VT01SA-VT01

• Ceiling: Steel plate spraying plastics frame ,acrylic lighting decoration
• Car wall: Hairline stainless steel+ mirror + etching
• Floor: PVC

SA-VT02 SA-VT02

• Ceiling: Sand-blast stainless steel, Creamy white wood decoration line ,crystal ceiling
• Car wall: Lightning beige marble, Wood decoration surface
• Handrail: Wooden handrail with stainless steel at both ends
• Floor: PVC

Optional Function

• Travel Function
• Man-Machine Interface
• Monitor Function
• Emergency Function
