iVolt - Model Single or 3 phase: 63-100A - Voltage Optimisation System

SHARE

Specifically designed for small areas or buildings without switch rooms. The modular range has all the features of the Commercial iVolt but only measures around 0.5m square (single phase) and can be installed side by side and stacked to provide a 3 phase unit. Single phase & 3 Phase units from 63 amps to 100 amps.

Most popular related searches
voltage optimization
circuit breaker
voltage optimization system
energy building management system
surge protection
industrial control transformer
energy management
condenser protection
energy management system
power transformer
  • Compact size and stackable  (Small footprint)
  • Ease of Installation. Less weight
  • Automatic integral bypass – for continuous supply
  • Technology: Microprocessor controlled transformer tap selection using thyristors
  • Capacity: 63A to >100A
  • Efficiency: 99.4% at full load
  • Response time: 15ms
  • Input voltage range: 253/438 volts down to 220/380 volts
  • Output voltage range: 220/380 volts, adjustable
  • Output accuracy: ± 1.5%
  • Phase control: Three phases balanced independently
  • Frequency: 47Hz to 75Hz
  • Waveform distortion: <0.25%
  • Transformer materials: Low loss electrical steel core with high purity copper conductors
  • Conductor Insulation class: Class H
  • Temperature class: Class B
  • Operating temperature: 0 – 55ºC
  • Operating humidity: 95% non-condensing
  • Ingress protection: IP21
  • Overload capacity: 150% for 4 minutes
  • Standards: BS EN 61558-1 2005, EN61000-6-4, IEC 61000-4-3, IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-11
  • Expected Service life: >25 years
  • Warranty: 15 years (parts and labour) on all transformer windings and electronic control boards
  • Circuit breaker(s): Input and/or output circuit breakers
  • Manual bypass: External manual bypass including isolation
  • Auto bypass: External auto bypass including circuit breaker for isolation
  • High level surge protection: Class 1 and 2 spike and surge protection
  • Protection L – N: 25kA @ 10/350μs
  • Protection N – PE: 100kA @ 10/350μs
  • Voltage protection level: 1.5kV
  • Remote monitoring system: Connection to energy management or building management systems
  • Harmonic reduction transformer: Reduced power harmonics from supply and load
