Waste Sorting and Incineration System
Our stationary waste utilization complex is equipped with a modern sorting line, combined with our incineration modules. The stationary incinerators ECO 1000 – 5000 provide bigger scaled solutions for the treatment of up to 45 tons of waste per hour.
1. CONTROL CABIN
The PLC programmable logic controller provides control and regulation of the main parameters of the eco complexes:
-
dosing and control of waste supply;
-
control and management of incineration processes;
-
control of the operation and performance of the flue gas cleaning system and auxiliary equipment;
-
and other more than 20 parameters
2. WASTE LOADING BUNKER
Automated system for supplying waste to the conveyor
3. DRUM SEPARATOR
Ensures breakup of bags and shredding pieces of garbage, screening out small construction waste (up to 4% of the total mass of waste).
4. CONTAINERS FOR SCREENING
Collection and discharge of screenings into a storage bunker for further disposal.
5. SORTING MODULE
6. CONTAINERS FOR COLLECTING USEFUL FRACTION
7. INTERMEDIATE BUNKER FOR LOADING AND SUPPLYING SORTED WASTE
8. INCINERATOR MODULE
9. GAS CLEANING MODULE
In order to comply with the environmental requirements of Ukrainian legislation and the norms of the European Community, when handling waste, the eco complexes provide for a 5-stage flue gas cleaning.
10. CHIMNEY
11. SILO COMPOSITION OF ASH RESIDUE
Automatic ash collection by pneumatic transport
