Model E-Series - WebMeter48

SHARE
The WebMeter48E™ is the next generation of affordable intelligent metering for your energy network. The fully enclosed meter is designed to accept voltage and amperage data from single, poly or three phase circuits. Pulse data from third party meters e.g. water, gas, steam, BTU, can be connected using the CircuitMeter JPulse-4™. The WebMeter48E™ accommodates any combination of up to 48 current transformers or pulse inputs to capture granular electrical and non-electrical information. Sampling rates up to 200,000 samples/second, the WebMeter48E™ delivers accuracy at the circuit-level and reports the information every 2 seconds to the CircuitMonitoring™ system providing a full spectrum of real time data.
Most popular related searches
current transformer
energy meters
energy meter
energy metering
energy consumption
energy network
power factor
energy management
energy metering system
energy management system
The WebMeter48E™ is a complete energy management metering solution allowing for widespread granular metering for industrial, commercial, institutional and multi-residential installations. At a dramatically lower cost per circuit with easy installation, the WebMeter48E™ is designed for economic deployment across a portfolio of facilities while metering at the individual circuit and equipment level.

WebMeter48™ Series

  • E-Series: UL Listed energy meter
  • S-Series: UL Registered energy meter

WebMeter48E™ Attributes

  • Produces up to 334 data points including amps, voltage, real power, energy consumption, power factor, reactive and apparent power, and operating “time on”
  • Standalone energy meter with complete enclosure for mounting adjacent to electrical box
  • Meets all UL 61010 standards (UL, CSA, CE)
  • Installed as a UL Listed product
  • Can measure up to 600VAC
  • Can accommodate any combination of single, poly and three phase loads
  • Supports up to 48 inputs of any combination of current transformers and/or pulse inputs via the JPulse-4™ supplied by CircuitMeter
  • Supports current transformers up to 6000A supplied by CircuitMeter
  • All features supported by the CircuitMonitoring™ system
  • One year memory @ 15 min intervals for energy consumption and generation when Internet is offline
  • Rechargeable capacitor that maintains internal clock for 24 hours
  • Supports global AC mains voltages 208V, 240V, 380-415V, 480V, 600V

Easy Installation

  • Compact one piece installation
  • Four (4) mounting screws
  • Pre-punched knockouts on three sides allows for universal mounting
  • Spring clip connectors for current transformer secondary wires, voltage wires, and JPulse-4

Connecting to the Internet

  • Industry standard RJ45 jack (T586B)
  • Fully encrypted UDP protocol
  • Cloud software configuration
  • Automatic remote updates
Supported AC Power Systems
  • 3 phase 4 wire 208 Wye/120V(3 Lines + neutral)
  • 3 phase 4 wire 380 Wye/230V (3 Lines + neutral)
  • 3 phase 4 wire 415 Wye/240V (3 Lines + neutral)
  • 3 phase 4 wire 480 Wye/277V (3 Lines + neutral)
  • 3 phase 4 wire 600 Wye/347V (3 Lines + neutral)
  • 3 phase 3 wire delta 208/240/380/415/480/600V no neutral
  • 1 phase 3 wire 120/240 V (a.k.a. split phase) with neutral

All configurations 50 – 60Hz (600V is 60Hz)

Safety Standards

  • UL 61010-1
  • UL 61010-2-030
  • CAN/CSA C22.2 No. 61010-1:2012
  • CAN/CSA C22.2 No. 61010-2-030-12
  • CE
  • Hi-pot test: 5.4 KV (5 seconds) 3.6 KV (60 seconds)
  • RoHS compliant

Accuracy1

  • ANSI C12.20 0.5 Accuracy Class

1 CERTIFICATION PENDING APPROVAL
