Movelaser - Model Molas B300 -Wind Lidars Doppler Wind Lidar
The Molas B300 series is an advanced all-fiber Doppler wind lidar system developed independently by Movelaser. Utilizing the Doppler frequency effect and eight-beam VAD scanning vector synthesis technology, it precisely measures wind speed and direction from 30 to 300 meters above the radar. It also incorporates sensors to monitor temperature, humidity, and air pressure. This lidar system is noted for its high measurement accuracy, stable performance, and low maintenance needs. It has passed stringent tests and certifications from renowned evaluation bodies, including WINDGUARD, China Meteorological Administration, and CE. The versatile Molas B300 can be employed in various scenarios such as wind resource assessment, post-assessment of wind farms, forecasting in wind power prediction systems, management of wind farm operations, atmospheric physics research, and meteorological monitoring and forecasting.It has passed the test and certification of the world's authoritative wind power evaluation agency WINDGUARD, China Meteorological Administration and CE.
The Molas B300 series, an all-fiber Doppler wind lidar independently developed by MOVELASER, is based on the Doppler frequency effect and uses eight-beam VAD scanning vector synthesis technology to measure the wind speed and direction 30-300m above the radar. Parameters such as temperature, humidity, air pressure, etc. are measured through the sensor module. Molas B300 has high measurement accuracy, stable system performance, easy maintenance, and safe and reliable data. It has passed the test and certification of the world's authoritative wind power evaluation agency WINDGUARD, China Meteorological Administration and CE. It has a wide range of applications and can be used in scenarios such as wind resource assessment, post-assessment of wind farms, wind power prediction systems, wind farm operation management, atmospheric physics research, and meteorological detection and forecasting.
General parameters
Powered by: 24V DC / 100~240V
Power: 70W
Size: 520*420*550mm
Weight: <50kg
Range of working temperature: -40℃ ~ 50℃
Operating humidity range: 0% to 100%
Protection class: IP65 (core module) / IP54 (complete machine)
Eye safety: Class 1M (EN60825-1)
Measurement parameters
Measuring distance: 30~300m
Measurement layer: 12
Sampling rate: 1Hz
Wind speed measurement accuracy: 0.1m/s
Wind direction measurement accuracy: 1°
Wind speed measurement range: 0~75m/s
Wind direction measurement range: 0~360°
Sweep cone angle: 28°
Wind resource assessment / Micro site selection and review / Wind power prediction system
Wind farm / wind farm performance evaluation / Weather detection
