W2E Wind to Energy GmbH
W2E - Model W2E-100/2.5 - Wind Turbine
Rated power: 2.5 MW. Rotor diameter: 100 m | 103 m. Wind class: IEC 2a. Drive train: LARUS Compact®.
Most popular related searches
- Rated power: 2.5 MW
- Rotor: 100 m | 103 m
- Wind class: IEC 2a
- Cut-in wind speed: 3.5 m/s
- Rated wind speed: 12.5 m/s
- Cut-out wind speed: 25.0 m/s
- Sound power: 105.4 dB(A) | 105.9 dB(A)
- Hub height tubular tower: 85 m | 100 m
- Hub height lattice tower: 105 m | 117 m | 141 m | 160 m
- Drive train concept - LARUS Compact®: Main gearbox in combination with torque bearing
- as a Plug & Play system
- Electrical configuration: Double-fed induction generator, IGBT converter, 50 Hz, 60 Hz
- Power control - LARUS Smart®: Triple independent pitch system
- Safety system - LARUS Safe®: Matrix safety system
