Minjie Continuous Vacuum Belt Dryer For Powder&Particle With Competitive Price - Video

Continuous vacuum belt dryer for free flowing powders and other heat sensitive products under vacuum

Website: www.mjdryer.com

E-mail: mj.info@shmjjx.com

Tel.: 86-021-68170260

Fax: 86-021-58172498

Address: No.338 Qinggao Road, Qinggang Industrial Park, Qingcun Town, Fengxian District, Shanghai, China.

Vacuum belt dryer is continuous infeed and discharge vacuum drying equipment. There are 3-11 layers of conveyor belts inside the cylindrical shell, the more the layers, and the larger the capacity. By feed and distributing device, the wet solid material is input continuously, and then distributed evenly on the conveyor belt under vacuum. Motion of the belt stirs the materials constantly, which speeds up evaporation, thus shortens the drying time, and also makes sure homogeneity during drying. The drying temperature and drying time (from feed-in to discharge) are adjustable（20-150℃）（20-80min）. If the dried product needs granulation, it can be comminuted under vacuum, no dust flying appears, which increases products'yielding and avoid contamination. The dried product is discharged continuously by vacuum discharging and collecting device. Organic solvent in the wet materials can be recycled by our system, removing pollution problem caused by traditional dryers, and adding profit.

Range of application:
1. Industries: Pharmaceutical, food, chemical, biological
2. Drying material state: Solid, crystal, particle, powder, pills
3. Some special material: Eeasy oxidation, easy explosion, strong stimulation, high toxicity
4. Material needing solvent recycling

ADVANTAGE
▪Bespoke engineered continuous drying solution to fit your requirements
▪Continuous and gentle drying preserving maximum colour, flavour and composition， and minimal oxidation
▪Individual temperature zones allow for product-specific profiles to be developed suited to each perfectly to each product
▪Less energy used than other drying methods
▪Viewing windows as standard allow for continuous monitoring, with options for automated monitoring systems available
▪Product specific feeding and discharging systems
▪Fully PLC automated operation & CIP cleaning system
▪GMP standards
