Ennox Biogas Technology GmbH products

In general the design for those flares is the same as for our standard flares. In accordance with the project-specific requirements (for example special gas composition, high gas temperatures or pollution) specific technical solutions and equipment are added. In principle all pyrolysis gas flares are individually customized, designed and calculated. All syngas flares have an own supporting burner or pilot burner as well special burners respectively combustion chambers. According to the requirements of the project special flare control systems, safety devices and fitting equipment can be delivered.

The NOXmatic comprises the most up-to-date quality gas are technology ensuring the safe, efficient and environmentally friendly combustion of gases from landfill, bio and sewage gas systems. Depending on the application parameters and the required combustion characteristics, the ares are supplied as either low or medium temperature units supplied with the required additional burner technology. For special requirements i.e., landfill gas application, the customer can implement our innovative and low emission NOXtor burner.

The modern preparation of biogas to more efficient, use and transport friendlier biomethane becomes more and more popular. During preparation of the biogas, removal of CO2 and other basic components of the gas resutls in a dramatic change of the gas specific Wobbe Index and therefore new requirements for specification of the flare burner. ennox gas flares can be specially configured for the burning of biogas and biomethane. The fully customized burner technology and combustion chamber design guarantees an efficient and environmentally friendly combustion of the gas. The complete ennox reange of accessories i.e, compressor station, temperature monitoring and winter packet can of course alse be used with the biomethane gas flare.

The high temperature are is the further developed NOXmatic are for the safe and low-emission combustion of land ll, bio or other special gases within a temperature range from 1000 – 1200 °C. In this temperature range the oxidising gas com- ponents are fully processed, thus greatly reducing the formation of nitrogen oxides.

Every year, millions of tons of household garbage and other refuse are deposited in landfills around the world. Biochemical decomposition processes of organic bonds in these landfills produce up to 150 – 250 m³ of landfill gases per tonne of household garbage. Due to a methane content of up to 60%, landfill gas ranks number six on the list of climate-disrupting methane producers worldwide, but it is also an important source of energy with enormous potential if used sensibly.

The low-price solution for the price-conscious farmer! Robust and compact manual gas flare for burning off biogas at agricultural biogas plants. Perfect for smaller new plants and for retro fitting to existing biogas plants. The operation of the eco gas are with a fermenter pressure of 3 mbar is possible although a minimum operating pressure of 10 mbar is always recommended. The eco gas flare ignites at the press of a button plus simultaneous actuation of the manual flap. To end the ring cycle, the manual flap is closed again. Eco 100 – 400 is supplied as a complete kit and can be quickly assembled on site according to the assembly instructions and installed. With appropriate preparation (foundations), the are is ready for use after 1 – 2h of construction. Expansion to automatic operation is possible – appropriate retro fitting kits are available at short notice.

Since the implementation of the Kyoto treaty the industry has seen a widespread development and tightening of regulations governing greenhouse emissions for the reduction of CO emissions. The issuing of the so called CO certificate not only calls for the Methane gas to be to be burnt in gas flares according to the UNFCC regulations, but also requires the logging and forwarding of the gas quantity and combustion data. In addition to flow rate and combustion measurement sensors with signal output, ennox delivers required gas flare systems, condensate drainage,gas cleaning, volume flow rate- and combustion temperature measurements components and compressor for CDM projects. We can fully customise the equipment for you to each and every project.

Biogas can contain large quantities of poisonous hydrogen sulphide depending upon the fermentation process and which input materials are used. This gas can cause permanent damage to gas engines or other consumers of the biogas. Depending on concentration, the majority of the hydrogen sulphide gas can be effectively removed by using an ennox active carbon filter.

Before the coarse filtered bio or sewage gas can be fed to the gas consumer it is normally passed through a ceramic fine filter. Here the gas is passed through a ceramic or reclay unit with a pre-determined pore diameter. Fine particles < 150 – 210 μm and condensate vapour are effectively removed. This eliminates any possible damage to components further on in the gas processing line. A variety of filter materials and filter sizes can be provided to meet the exact requirements of the application.

The gas condensate accumulator is used for both the collection of condensate water within the gas system and for drainage. Normally the condensate accumulator is integrated directly into the lowest point of the pipework by means of a flange connection. The condensate water flows into the collection container and is drained either through a ball valve, or automatically with a condensate drainage unit. The condensate accumulator is available in two sizes, according to the requirements of the system.
