PV Ground Mounted - Guiglia, Case Study

wwsolar park Guiglia 6.16 MWpwww.scatecsolar.comElectrical design in the solar park: 25,938 solar modules laid out in 1,179 strings. 9 outdoor inverter stations and MV-transformers. Each has a transformer station.The solar park is monitored using remote data transmission methods and monitoring software which offers a high level of internet support. Ramming system, partly strengthened with concrete plug.Headquarter Oslo, NorwayScatec Solar ASSommerrogaten 13-15 NO-0255 Oslo, Norwaykommt besseres Bild von Wernerkommt besseres Bild von WernerProfile of the solar park GuigliaBasic dataSize of area: 200,000 square meters (solar field)Location: Italy, near ModenaInstalled capacity: 6.16 MWp (nominal, DC)Electrical design: 9 outdoor inverters, 81 string-monitorsPV modules: 25,938 PV modules in 1,179 strings (235 - 240 Wp each, Si, polycrystalline)Global Solar 1,257 kWh / m2 / year Irradiation: (in horizontal plane)Specific yield: approx. 1,228 kWh / kWp p.a. (“normal” year)Performance Ratio: approx. 83.5 %Energy yield: approx. 7,572 MWh per year (first full year)Ecolocical profileCO2 savings approx. 4,554 t per yearClean energy for 6,310 citizens (approx. 1,200 kWh per year / citizen energy consumption)Photo was taken during construction phase.
