Beanair GmbH

BeanDevice - Model AN-mV Xtender - Analog Voltage Data Logger

The BeanDevice® AN-mV Xtender is a wireless data logger with analog voltage inputs (±20mV). Special care is taken in the analog signal conditioner design with an accuracy of ±0.4% (FS) and a dynamic range of 16-bits. The BeanDevice® AN-mV Xtender comes with an integrated data Logger that can store up to 1 000 000 data acquisitions. The sensor is directly powered by a high accuracy and adjustable DC/DC converter integrated inside the device. The excitation voltage is remotely configurable through the BeanScape® (4.5 to 20V). This device is powered by Lithium-thionyl chloride primary battery with a capacity of 6.5 Ah. Characterized by a watertight (IP65) and small (146.05 mm x 65.5 mm x 33.5mm) aluminum enclosure, an ultra-low power (30 µA in sleeping mode), an integrated data logger that can store up to 1 000 000 data acquisitions, as well as a maximum wireless range of 1 Kilometer (L.O.S.), this wireless device is well suited for all types of industrial applications.
