SIGSO - Model BMS 24V 144Ah - Battery Management System
The BMS 24V 144Ah from SIG Technology is designed for effective battery management in various applications. This robust system provides reliable control and monitoring of battery parameters essential for ensuring optimal performance and safety. It is capable of managing the critical task of balancing cell-charging processes while simultaneously protecting against overcharging or deep discharging, thus enhancing battery longevity. The system is engineered to integrate seamlessly with other components such as cells and modules, making it indispensable for energy storage solutions across numerous industries. Its design emphasizes precision and reliability to meet the rigorous demands of modern energy systems and ensure compliance with industry standards.
DESCRIPTION
- Reference : BMS24V144Ah
- Dimension : 490mm x 95mm x 22mm
- Weight : 240 g
MECANIC AND DESIGN
- Cell busbars : Integrated
- Distance between cells : 2mm
- Working temperature : -40 °C ~ 85 °C
SECURITY
- Design : EMC compatibility
- Alarm settings : Current; Temperature; Voltage
- Alarm : Integrated Buzzer
- Certification : ISO 26262; RoHS
MANAGEMENT BATTERY PACK PERFORMANCE
- Topology : Master / Slave (distributed on each cell)
- Balancing : Dynamic: Active up to 1 A & Passive up to 500 mA
- Accuracy of cell voltage measurement : ± 2 mV
- Accuracy of pack voltage measurement : ± 300 mV
- Accuracy of cell temperature measurement : ± 2 °C
- Accuracy of current measurement : ± 500 mA
- Current sensor : Hall effect
- Communication protocol : CAN BUS (CAN 2.0/B) 62.5 KPBS
- Communication between cards : Optoisolated UART
- Standby consumption : 30 μA
