Biogasclean - Low Oxygen Biological Desulphurisation System
Biological desulphurisation with low O2 for high availability with low OPEX costs
By injecting pure oxygen, our 100% biological desulphurisation system operates with a guaranteed maximum oxygen surplus of 0.3 %, meeting the required specification for injection into the natural gas grid. This eliminates dilution with nitrogen and ensures the biological desulphurisation system can be located upstream on all types of biogas upgrading systems, like membranes, water scrubbers and PSAs.
The most important differences between Biogasclean’s solutions and alternative biological H2S removal systems are safety and automatic reliable operation.
- Safety. Injection of air into biogas is possible with a control system; without there is a substantial risk of creating dangerous situations with explosive mixture. Therefore, Biogasclean systems are supplied with a control system which will adjust air injection to the actual biogas flow and stop air injection in case there is no biogas flow. If the PTU is closed, the safety system will also remove the ignition source by cutting the power supply in case the gas detector should measure methane above 25% of the Lower Explosive Level (LEL).
- Safety – Learn more ?
- Automatic reliable operation. Safety is mandatory; but on top of that the control system also secures good performance even with fluctuations in the biogas flow. The system is automatically controlled by the PLC controller board which reduces the risk for manual errors and operation problems. The main function is to provide safe, optimal and stable conditions for the biological process. The signals can be made available in the control room.
- Low operating costs. The system uses no chemicals and has a very low electrical consumption. In many projects we use treated water from an anaerobic digester or an aeration pond as scrubber liquid and nutrient source. This is easily accessible and cheaper than water and industrial fertilizer.
- Guaranteed performance. We provide performance guarantees on all projects.
Working entirely without ferric chloride, caustic soda, iron sponge or activated carbon, the system operates at much lower cost, providing the most economical solution.
When considering both CAPEX and OPEX, biological desulphurisation is much more cost effective than chemical or solid media solutions.
The uptime of our solution exceeds 98%, which when combined with guaranteed performance on all projects makes Biogasclean H2S reduction with low oxygen the obvious choice.
