Boostsolar - Model BSL2436DD01 -Double-Deck Double-Chamber Solar Module Laminator

Effective Laminating  Area 2400 mm × 3600mm×4. Overall Dimension  17700mm×3540mm×2900mm  (only laminator exclude auxiliary tools such as vacuum pump and heating station）. Heating type heating transfer oil. Compressed Air Pressure  0.6～0.8MPa. Working Vacuum Degree   100～40Pa. Evacuation Speed  ≥70L/S. Precision of Temperature Control    ±1.5℃.
Temperature control range  Room Temperature--180℃. Temperature Uniformity Laminating area≤±2℃. Height of laminating chamber 30mm. Evacuation Time   Depending on the process, suggesting: 5～8min. Cover moving range 200mm
