AEG - Model ARE i9 LF - Compact Reader
The ARE i9 LF reader combines all common LF algorithms in one device. The extremely compact design and the possibility of mounting directly on metal makes it an ideal reader for all industrial applications.
Most popular related searches
ELECTRICAL CHARACTERISTICS
- reading system ASK, PSK, HDX, Trovan
- operational frequency 125 kHz, 134.2 kHz
- interface RS232 (M12 - 5-Pin A coded male)
- software Easy serial ASCII based control protocol
- power supply 7,5V DC
- Antennas Internal air core coil
ENVIRONMENT
- storage temperature -20°C up to +70°C
- operating temperature -20°C up to +70°C
- housing protection IP 65
- schock & vibration IEC 68-2-6 / 29
DIMENSIONS
- Weight Ca. 100 g
- Length 55 mm
- Width 42 mm
- Height 23 mm
- Material PC
