Nema - Model Type 4X - N72HS3616SS6WPLS -Free Standing Single Door Enclosures
FromNema Enclosures
Nema Enclosures manufactures standard and custom free standing powder coated carbon steel, 304 stainless steel, 316 stainless steel and 5052 aluminum electrical enclosures provide protection for systems incorporating large components or in complex mounting configurations. All free standing electrical enclosures are NEMA rated, UL listed and/or IP rated.
Most popular related searches
- Ships in 10 Days
- All Stainless Steel Hardware
- #4 Brushed Finish
- Includes Powder Coated Back Panel
- Collar Studs provided for back panel mounting
- Leg Stand is welded to bottom of enclosure
- Ground Studs provided on the interior of the enclosure and door
- UL Listed per UL File Number E130533/IP66
- Weight (lbs.) 540.0000
- Enclosure Type Free Standing
- Enclosure Material 316 Stainless Steel
- Enclosure Feature Clamp Cover
- Door Single Door
- Height 72
- Width 36
- Depth 16
- Nema Rating 4X
- IP Rating N/A
- Back Panel Carbon Steel
- 2D CAD Drawing N72HS3616SS6WPLS DXF
- 3D PDF Drawing N72HS3616SS6WPLS 3D
- 3D Step Drawing N72HS3616SS6WPLS.STEP
