Hention - Model TORP Series" -Transformer Oil Regeneration Plant

Technically speaking, oil oxidation starts once the transformer is put into use and energized. Under the influence of high temperature and oxygen, acids, polar compounds and other dissolved decay products will build up, and turn into sludge, which accelerate the oxidation process. In this way, oil insulation properties continuously degrade and oil color becomes darker.

After years of service inside electrical transformers, the dielectric oil becomes so deteriorated that oil regeneration system is required to help eliminate sludge from oil. Reconditioning process will greatly prolong insulating oil service life, and the reclaimed oil can be regarded as qualified as new oil again.

• Processing capacity from 2000 to 10000 liter/hour
• Pure physical recovery for aged transformer oil
• Well structured regeneration columns
• High efficient adsorbent activated clay
• Oil color recovery with Fuller`s Earth
• Reduce acids and corrosive sulfur from deteriorated oil
• Improve interfacial tension and power factor
• Environment friendly

• Open skid base
• Customizable design, material and components
