Adaptronic - Model NT 231 -High-Voltage Tester With PC Control
The NT 231 high-voltage tester with PC control offers up to 512 test points and checks up to 1000 VDC. Optimized for operation on test panels and test desks. The NT 231 wiring tester, the smallest high-voltage tester in adaptronic''s NT series, was specifically developed for operation on test desks and test benches. With functions such as adapter LEDs, an insertion aid for the production of wire harnesses, and interfaces for cutters, embossing units, and other peripheral equipment, the NT 231 is versatile for connection, short-circuit, insulation, and component testing.The included NT Control software package enables intuitive operation via PC. Test programs can be easily created, edited, and managed and the test results logged. The user interface is available in different languages to meet individual requirements.
NT 231
Metric
- Control software: NT Control
- Test of other components: Diodes, LEDs, Zener diodes, varistors, surge arresters
- Interfaces: Network 4 x USB. Pin number probe. Connection option for red-green warning lamp. Foot switch. Test result indicator
- Dimensions/height: 140 mm
- Width: 235 mm
- Dimensions/depth: 275 mm
- Weight: ca. 3.5 kg
- Voltage (AC), input max.: 230 V
- Frequency, input min.: 50 Hz
- Frequency, input max.: 50 Hz
- Voltage, input, connector: Protective contact plug (240 V, 16 A, 3-pole)
- Ambient temperature, operation min.: 10 °C
- Ambient temperature, operation max.: 40 °C
- Ambient temperature, storage min.: 10 °C
- Ambient temperature, storage max.: 60 °C
- Air humidity non-condensing min.: 30 %
- Air humidity non-condensing max.: 70 %
- Test voltage (DC) max.: 1000 V
- Test current (DC) max.: 400 mA
- Test points, total max.: 512
- Continuity test via threshold identification min.: 1 Ω
- Continuity test via threshold identification max.: 1 kΩ
- Short-circuit test via threshold identification min.: 20 kΩ
- Short-circuit test via threshold identification max.: 1 MΩ
- Resistance measurement min.: 1 Ω
- Resistance measurement max.: 1 MΩ
- Capacitance measurement min.: 10 nF
- Capacitance measurement max.: 0.01 F
- High voltage test (DC) max.: 1000 V
- DIO voltage max.: 24 V
Imperial
- Control software: NT Control
- Test of other components: Diodes, LEDs, Zener diodes, varistors, surge arresters
- Interfaces: Network 4 x USB. Pin number probe. Connection option for red-green warning lamp. Foot switch. Test result indicator
- Weight: ca. 7.7 lb
- Voltage (AC), input max.: 230 V
- Frequency, input min.: 50 Hz
- Frequency, input max.: 50 Hz
- Voltage, input, connector: Protective contact plug (240 V, 16 A, 3-pole)
- Ambient temperature, operation min.: 50 °F
- Ambient temperature, operation max.: 104 °F
- Ambient temperature, storage min.: 50 °F
- Ambient temperature, storage max.: 140 °F
- Air humidity non-condensing min.: 30 %
- Air humidity non-condensing max.: 70 %
- Test voltage (DC) max.: 1000 V
- Test current (DC) max.: 400 mA
- Test points, total max.: 512
- Continuity test via threshold identification min.: 1 Ω
- Continuity test via threshold identification max.: 1 kΩ
- Short-circuit test via threshold identification min.: 20 kΩ
- Short-circuit test via threshold identification max.: 1 MΩ
- Resistance measurement min.: 1 Ω
- Resistance measurement max.: 1 MΩ
- Capacitance measurement min.: 10 nF
- Capacitance measurement max.: 0.01 F
- High voltage test (DC) max.: 1000 V
- DIO voltage max.: 24 V
