Light Catcher - Model LCS-30PP - Mid-Range Solar Controller
LightCatcher-Solar leading mid-range solar controller for both professional and consumer applications. Features include state of the art protections using highly advanced technology. Provides longer battery life and improved system performance.
Most popular related searches
solar controller
lightning and surge protection
surge protection
power cable
battery performance
solar array
lightning surge protection
lightning surge
voltage optimization
load current
Detailed Description
- Short-circuit protection — solar and load
- Overload — solar and load
- Reverse polarity
- Reverse current at night
- High voltage disconnect
- High temperature disconnect
- Lightning and transient surge protection
- Loads protected from voltage spikes
- Automatic recovery with all protections
Charging
- Night Disconnect: The solar array automatically disconnects at night to prevent reverse current leakage from the battery.
- Battery Sense: Good battery performance requires accurate charging. Voltage drops in the battery power cables can distort the battery charging. The Sense wires eliminate the voltage drops for optimized charging.
- Temperature Compensation: Four control setpoints (25°C reference) are compensated for temperature (PWM regulation, float, equalization, high voltage disconnect). The charging is compensated by –5 mV/°C /cell (–30mV/°C for a 12V battery). Compensation is limited to minus 30°C.
