Adaptronic - Model NT 236 -Mobile High-Voltage Wiring Tester System
The NT 236 mobile high-voltage tester in a hard-shell case without a display tests insulation at up to 512 test points up to 1000 VDC and test voltages of 80 - 1000 V. The NT 236 HV wiring tester is a mobile solution for your wiring tests and comes in a heavy-duty, waterproof, and dust-proof hard-shell case.Providing high-voltage tests up to 1000 VDC and the ability to test with up to 512 test points, the NT 236 can be flexibly used for quality assurance in the fields of aviation, railway technology, or military technology.Versatile test options from connection and short-circuit tests to component tests are documented in comprehensive result logs and optionally can be transferred to a database by using OPC UA, SQL, or other network software. The associated NT Control software effortlessly creates complex test programs and documents process steps up to the completed test.
NT 236
Metric
- Control software: NT Control
- Test of other components: Diodes, LEDs, Zener diodes, varistors, surge arresters
- Dimensions/height: 229 mm
- Width: 487 mm
- Dimensions/depth: 386 mm
- Weight: > 8 kg
- Voltage (AC), input max.: 230 V
- Frequency, input min.: 50 Hz
- Frequency, input max.: 50 Hz
- Ambient temperature, operation min.: 10 °C
- Ambient temperature, operation max.: 40 °C
- Ambient temperature, storage min.: 10 °C
- Ambient temperature, storage max.: 60 °C
- Air humidity non-condensing min.: 30 %
- Air humidity non-condensing max.: 70 %
- Test voltage (DC) max.: 1000 V
- Test current (DC) max.: 400 mA
- Test points, total max.: 512
- Continuity test via threshold identification min.: 1 Ω
- Continuity test via threshold identification max.: 1 kΩ
- Short-circuit test via threshold identification min.: 20 kΩ
- Short-circuit test via threshold identification max.: 1 MΩ
- Resistance measurement min.: 1 Ω
- Resistance measurement max.: 1 MΩ
- Capacitance measurement min.: 10 nF
- Capacitance measurement max.: 0.01 F
- High voltage test (DC) max.: 1000 V
- DIO voltage max.: 24 V
Imperial
- Control software: NT Control
- Test of other components: Diodes, LEDs, Zener diodes, varistors, surge arresters
- Weight: > 17.6 lb
- Voltage (AC), input max.: 230 V
- Frequency, input min.: 50 Hz
- Frequency, input max.: 50 Hz
- Ambient temperature, operation min.: 50 °F
- Ambient temperature, operation max.: 104 °F
- Ambient temperature, storage min.: 50 °F
- Ambient temperature, storage max.: 140 °F
- Air humidity non-condensing min.: 30 %
- Air humidity non-condensing max.: 70 %
- Test voltage (DC) max.: 1000 V
- Test current (DC) max.: 400 mA
- Test points, total max.: 512
- Continuity test via threshold identification min.: 1 Ω
- Continuity test via threshold identification max.: 1 kΩ
- Short-circuit test via threshold identification min.: 20 kΩ
- Short-circuit test via threshold identification max.: 1 MΩ
- Resistance measurement min.: 1 Ω
- Resistance measurement max.: 1 MΩ
- Capacitance measurement min.: 10 nF
- Capacitance measurement max.: 0.01 F
- High voltage test (DC) max.: 1000 V
- DIO voltage max.: 24 V
