Model BEM 255Wp - Monocrystalline Photovoltaic Modules
From Monocrystalline Photovoltaic Modules
Maximum power [Pmax]: 255. Cells: Monokrystaliczne Si. Size: 156 x 156 mm. Nr of cells: 60. Short circuit current [Isc]: 8,9. Open circuit voltage [Voc]: 38,1. Maximum power current [Imax]: 8,38. Maximum power voltage [Vmax]: 30,45. Module efficiency: 15,70 %. Maximum system voltage: 1000 V DC. Tolerance: 0 +4,99. Temperature coefficient current TcI: +0,03 %/°C. Temperature coefficient voltage TcV: -0,32 %/°C. Power temperature coefficient TcP: -0,39%/°C. NOCT(800 W/m2, 20°C, AM 1.5, 1m/s): 43 °C
-
Most popular related searches
25year linear warranty
- 25year linear warranty
- 100% electroluminescence inspection
- Guaranteed positive power tolerance
- Maximum 5400 Pa snow load
- IP 67 junction box available, long term weather endurance
- Innovative solution: anti-reflective coating for high sunlight absorption
- Potential Induced Degradation FREE High quality components
- Packing system to avoid micro cracks
Qualification Test Parameters
- Maximum load:IEC 5400 Pa
- Application class:A
Physical Characteristics
- Length:1640 mm
- Width:992 mm
- Thickness:38 mm
- Weight:18 kg
- Junction box:IP 65
