Model BEP 250Wp - Multi-Crystalline Photovoltaic Module
From Multi-Crystalline Photovoltaic Modules
Maximum power [Pmax]: 250. Cells: Polycrystalline Si. Size: 156 x 156 mm. Nr of cells: 60. Short circuit current [Isc]: 8,75. Open circuit voltage [Voc]: 38,1. Maximum power current [Imax]: 8,25. Maximum power voltage [Vmax]: 30,35. Module efficiency: 15,40 %. Maximum system voltage: 1000 V DC. Tolerance: 0 +4,99. Temperature coefficient current TcI: +0,05 %/°C. Temperature coefficient voltage TcV: -0,34 %/°C. Power temperature coefficient TcP: -0,41%/°C. NOCT(800 W/m2, 20°C, AM 1.5, 1m/s): 42 °C
-
Most popular related searches
25year linear warranty
- 25year linear warranty
- 100% electroluminescence inspection
- Guaranteed positive power tolerance
- Maximum 5400 Pa snow load
- IP 67 junction box available, long term weather endurance
- Innovative solution: anti-reflective coating for high sunlight absorption
- Potential Induced Degradation FREE
- High quality components
- Packing system to avoid micro cracks
Qualification Test Parameters
- Maximum load: IEC 5400 Pa
- Application class: A
Physical Characteristics
- Length: 1640 mm
- Width: 992 mm
- Thickness: 38 mm
- Weight: 18 kg
- Junction box: IP 65
