bewind - Model BW 14.xM225 -Offshore Wind Turbine
The BW 14.xM225 is a cutting-edge offshore wind turbine designed to meet the demands of challenging maritime environments. Engineered by BW Wind Technologies, this turbine is the culmination of decades of experience in the multi-megawatt offshore sector. It boasts the most powerful drivetrain available in the market, renowned for its reliability and efficient performance. The design ensures an optimal energy yield and competitive Levelized Cost of Energy (LCoE) for offshore installations. It is built in compliance with DIN ISO 9001 standards, ensuring high quality and consistent production. The turbine is an ideal solution for large-scale offshore energy projects that require robust and trustworthy machinery to harness wind energy effectively. This turbine represents a significant leap forward in offshore wind technology, offering both innovation and proven performance.
Our solution for your offshore challenges. Based on decades of multi-megawatt offshore experience, this turbine features the world’s most powerful drivetrain with unbeaten reliability. For your challenging offshore applications, our turbine delivers leading energy yield and lowest LCoE.
Turbine :
- IEC class : IEC I S (Taifun)
- Rated power : 14,xxx kW
- Cut-in wind speed : 3.0 m/s
- Nominal wind speed : 12.0 m/s
- Cut-out wind speed : 25.0 m/s (30.0 m/s with derating)
- Ambient temp operation : -10 ˚C to +45 ˚C
- Ambient temp structure : -30 ˚C to +50 ˚C
- Design lifetime : 30 years
- Standard air density : 1.225 kg/m³
- Sound power level : 108 dB(A)
Rotor :
- Blade length : 110 m
- Swept area : 39,761 m²
- Material : Carbon-fiber reinforced plastic (CFRP)
Drivetrain :
- Gearbox type : 2-stage gearbox, planetary gear system
- Generator type : PMSG
- Converter Type : Full converter
