Solar Defender - Model ALM-6816 - Pocket Module with Torsion for Optical Fiber, 1 Loop, 12Vcc

Supply and installation of Pocket Module for Plastic Optical Fiber Solar Defender with torsion 12Vcc. Manage 1 Lines of optical fiber lenght 200 mt. Double-mode to detect fiber alarm signals: interruption and torsion. Operation mode Stand-alone. alarm conditions: alarm detected by fibre interruption and torsion. Signal Outputs: Alarm by fiber interruption, alarm by fiber torsion, Life, alarm tamper box. Certifications CE, REACH, RoHS Compliant. Included the necessary electrical and signal connections, materials and charges, at workmanlike manner. MARSS ALM-6816 model.

The Plastic Optical Fiber is installed on the panels in a way to make impossible the theft without to break or twist the same one. When a fiber interruption and/or a torsion happens, a special optical receiver detects the change of the light transmitted by the fiber and send the information to a system of concentrator modules. These ones manage the alarm about the operating mode selected by the user: stand-alone and on BUS.

The fiber is installed as a “close ring” between the panels. Sigillo, the innovative fastening system Marss patented, allows the proper and quick installation of the fiber at the panel, without mistakes, and than malfunctioning in the systems.

The fiber installation does not require masonry works, excavation or pipe.

• Detects from thefts the single line of panels, in a simple and safe way, thanks to the communication protocol owner Marss.
• Quick and easy installation without the use of special tools
• Can be installed on any type of panel and photovoltaic plant
• Modular system, integrable and interfaceble
• Double operation mode selectable by the user
• Function "Cantiere Protetto".
• H24 working
• False alarm immunity
• Patent Marss.
