Aaronia SPECTRAN - Model V6-X USB - Real-Time Spectrum Analyzers
The Aaronia SPECTRAN-V6-X series are high performance real-time spectrum analyzers for USB with a RTBW (real-time bandwidth) up to 245 MHz (via 2x USB). With a sweep speed of over 1 THz/s, the devices set new standards in the USB compact class. Any number of devices can be cascaded to achieve an even higher real-time bandwidth. For example, a real-time bandwidth of 1 GHz is already achieved by using four SPECTRAN-V6-X devices. The stackable aluminum housing facilitates the parallel use of multiple units.
The "RTSA-Suite PRO" software is included in the scope of delivery. It is perfectly tailored to the hardware and also supports the use of multiple SPECTRAN-V6-X units. The RTSA-Suite PRO allows to display and analyze signals in real-time in many different ways.
- USB real-time spectrum analyzers.
- Frequency range 10 MHz...6 GHz (optionally up to 8 GHz).
- Multiple instruments cascadable.
- Unlimited continuous 245 MHz true I/Q streaming via 2x USB 3.0.
- Dual receiver real-time bandwidth 245 MHz.
- I/Q vector signal generator up to 245 MHz Tx.
- Sweept 6 GHz in less than 5 ms (1 THz/s).
- Parallel measurement of multiple frequency bands.
- POI up to 97 ns (FFT-based) or up to 10 ns (I/Q-based).
- 16 bit ADC at 2 GS/s for exceptional dynamic range.
- Sample rate 500 MS/s (16 bit dual 256 MS/s I/Q data).
- FFT rate 960 million FFT points/s (120 million FFTs/s).
- Full MATLAB support.
- Including software "RTSA-Suite PRO" with daily updates.
- Made in Germany.
Benefits of the SPECTRAN-V6-X RSA up to 80, 160, or 245 MHz
- 6 or 8 GHz USB spectrum analyzers with dual USB true I/Q streaming up to 245 MHz.
- Extremely small POI down to 10 ns for extremely short signals.
- Vector signal generator/tracking generator with modulation bandwidth up to 245 MHz.
