FCT - Model Type FP H -Resistance Heated High-Temperature Pressure Sintering Furnace with Integrated Hot Pressing Function
FromFCT Systeme GmbH
In addition to conventional gas pressure sintering, also known as Sinter-HIP, this furnace type is particularly characterized by its high flexibility and the ability to combine it with other sintering methods. Sintering under vacuum and partial pressure, as well as gas pressure sintering up to 100 bar, can be implemented—along with combinations of all these atmospheres with uniaxial hot pressing.
Most popular related searches
sintering furnace
high-temperature sintering furnace
furnace
high temperature furnace
gas plant
wall heating
heating and cooling
- sintering in vacuum, relative pressure, overpressure up to 10 MPa
- Hot pressing up to 125 kN
- Combined process of all sintering atmospheres with uniaxial presses
- Debinding and/or dewaxing as a combined process
- High flexibility in process optimization and design
- Extensive data evaluation
- Product development, prototype production
- Design: bottom loading (vertical design)
- Temperature measurement using pyrometer
- Working temperature up to 2000°C at 10 MPa
- Vacuum: 5x10-² mbar(a)
- Furnace atmosphere: Ar / N2 / forming gases
- sensitive lifting of the container base (loading and unloading)
- safe and certified closure system (bayonet closure)
- Easy accessibility
- Resistance heating
- Double-walled, water-cooled vacuum container
- Comprehensive user-friendly control system Siemens S7 and WinCC
- Working temperature up to 2200°C
- Various gas mixtures can be regulated
- Debinding / dewaxing
- Dilatometer (In-situe measurement)
