FCT - Model Type FH I -Resistance Heated High-Temperature Vacuum Sintering Furnace
FromFCT Systeme GmbH
Due to their induction heating, induction-heated high-temperature vacuum sintering furnaces are used especially for large furnace volumes and application temperatures of up to 2500 °C. As a result of the uniform energy output, the inductively heated graphite susceptor achieves very good temperature uniformity even at high temperatures of 2500 °C and more. The higher investment cost compared to resistance heated furnaces is offset by a much longer service life.
Most popular related searches
high-temperature sintering furnace
sintering furnace
high temperature furnace
furnace
energy output
gas main
gas cooling
- Working temperature up to 2500°C (even up to 2800°C on special request)
- Vacuum: 5 x 10¯² mbar(a)
- Furnace atmosphere: Ar / N2 / forming gases
- Extended heating zones up to max. 3000 mm
- Debinding and/or dewaxing as a combined process
- Rapid cooling with internal gas circulation (as option)
- Special sizes and functions on request
- Special solutions for C/C and C/SiC composites
- Special solutions for graphite purifiing
- Design: horizontal with swivel door
- Temperature measurement using pyrometer
- Furnace atmosphere: Ar / N2 / forming gases
- Induction heater
- Double-walled, water-cooled vacuum chamber (vessel)
- Comprehensive, user-friendly Siemens S7 control system with WinCC
- Working temperature up to 2800°C
- Debinding and/or dewaxing as a combined process
- Different gas mixtures adjustable
- Rapid cooling with internal gas circulation (as option)
