Rotary Kiln
Opportunities must be taken! Rotary kiln technology enables environmentally friendly energy production by the combustion of various by-products and waste materials. With rotary kiln technology, Werkstätten heating-systems GmbH provides future-proof answers to pressing questions facing agriculture, industry and local authorities today. We develop holistic thermal concepts with the rotary kiln for the independent and efficient recycling of material flows such as foliage, fermentation residues, seed stock or sewage sludge. Easy to use, self-cleaning and fully automatic, the combustion technology offers maximum efficiency in times of great political and economic pressure.
Under the umbrella of the Werkstätten Group, Werkstätten heating-systems GmbH participates in the combined experiences and competences. Our customers can rely on our professional planning and execution, our high level of ambition and our personal commitment. We provide comprehensive services and always think a little bit further ahead for each project. Rotary kiln technology also has great potential which must be exploited jointly with smaller and medium-sized local authorities, associations and businesses.
- Modular design and container solution offer flexibility in terms of location
- Flexible PLC control for regulating the boiler and integrating upstream and downstream components
- Oxygen and load-controlled automatic charging and combustion via dynamic PLC control system
- PLC control with clear visualisation and the option of remote monitoring and manufacturer support
- Water-cooled, rotating combustion zone with divided ventilation zones for supplying fuels with combustion air
- Energetic use of a wide variety of biomasses
- Slag-free combustion of the most difficult fuels
- Very low CO content in the flue gas prevents caking in the heat exchanger
- Almost stoichiometric combustion in innovative rotary kiln
- High efficiency due to constant material circulation
- Automatic ignition
- Automatic ash removal
- Rated heat output: 500 — 5.000 kW
- Partial load: 150 — 1.500 kW
- Approval according to 4th + 17th BlmSchV possible
- Permissible water temperature: 105 °C
- Permissible Thermal oil temperature: 400 °C
- Steam, saturated steam + superheated steam
The user-friendly, self-cleaning and fully automatic combustion technology has an innovative, water-cooled rotary tube technology with a number of advantages:
- Suitable for fuels with low ash melting point and high ash content
- Combustion extends over the entire length of the rotating tube with a turbulent flame vortex
- All boiler components exposed to wear and/or high heat loads are lined with refractory and wear-resistant concrete
- In an insulated post-combustion chamber, the flue gases are completely burnt out before they enter the heat exchanger
- Emission values according to the 4th and 17th BImSchV, depending on the fuel, are significantly undercut.
- The powdery ash is low in carbon and free of slag; the nutrient salts it contains are available to plants and can be used as fertiliser Possible forms of energy are
- hot water, steam and/or thermal oil
