Greenstar Superplus - Steam Boiler
GREENSTAR SUPERPLUS is the most super-efficient boiler having104% overall thermal efficiencybased on net calorific value (NCV or LHV) of Natural Gas. GREENSTAR SUPERPLUS has five-pass configuration, two passes of smoke-tube type main boiler and the third, fourth and fifth pass in the form of economizer, two water preheaters (condensing and non-condensing), as heat recovery units, to achieve maximum thermal efficiency. GREENSTAR SUPERPLUS is the most compact, lightweightsmoke tube boiler,most suitable where space availability is very limited.
- 104% overall thermal efficiencybased on net calorific value (NCV or LHV). The104% overall thermal efficiencyresults in large fuel savings.
- Thisgas fired boilerGREENSTAR SUPER has optimized configuration of heating surfaces and tube sizes for efficient operation of the boiler.
- Thudiyalur (post) Coimbatore – 641 034. Tamilnadu, India
- Phone: 422-2642484 Fax : 0422-2642128 Email : , Steam Output (F&A 100°C) 1 Ton/hr to 34 Ton/hr or Higher
- Safety Valve Set Pressure, bar(g) 10.54 / 17.5 / 21.0 / 25.0 or Higher
- Maximum Steam Temperature Dry & Saturated Or Superheated
- Thermal Efficiency 104% on NCV/LHV of Natural Gas
- Steam Generation Control Step-less Modulation
- Combustion Control Step-less Modulation
- Draft Control Step-less Modulation
- Efficiency upgradation services
- Performance trials as per direct and indirect method
The GREENSTAR SUPERPLUS, a compactcondensing boiler,i.e. – boiler withcondensing water-preheater,having104% overall thermal efficiency,is used for cost effective industrial process heating applications, at highest thermal efficiency.
