Rocky, sensitive, or steep terrain. Terri 3FW makes forwarding a pure joy. Two of the reasons are spelled high ground clearance (70 centimetres) and easy-to-maneuver driving. This makes the machine a stable and reliable working partner.
Regardless of the terrain, you can be sure that after a day of forwarding, the result will be perfect. And should additionally bearing capacity or traction be needed, it is of course possible to fit tracks as well as chains to the wheels. The agility is further enhanced thanks to a variable wheelbase and that the rear bank is slidable forward and backward.
With Terri you can expect comfort with high quality. Step into an airy and spacious cabin, equipped with technology and amenities that make the days both enjoyable and smooth. The fully automatic air conditioning system ensures comfortable air circulation with the right temperature.
Engine
- Diesel engine:CAT 3.6
- Power:55.4 kW
- Number of cylinders:4
- Torque:424 Nm/1 200 rpm
- Diesel tank volume:100 l
Crane
- Crane:Mowi
- Model:P30T/P40/P40T
- Lifting torque:37 kNm
- Slewing torque:12 kNm
- Slewing arc:360º
- Reach:6,7/6,2/7,5m
Transmission
- Transmission:Fully hydraulic
- Max. steering angle:45º
- Gears:1, 2, 3 & reverse
- Max. speed:13/18 km/h
- Wheel dimension:425 alt 500/50 x 17
Chassis
- Service weight:6,100 kg
- Length, standard:6,600–7,200 mm
- Length, extra long:7,200–7,800 mm
- Width :1980 mm – 2050 mm
- Highest height:3,100/3,180 mm
- Ground clearance :700 mm
- Loading area:2–2.45 m2
- Loading capacity:6.0 tons
Hydraulic system
- Hydraulic system:Danfoss
- Tank volume:120 l
- Pump capacity:115 cc
Electrical system
- Electrical system:24 V
- Battery:2x12 V / 100 Ah
- Generator:100 A
