Three Phase Synchronous Generators
The brushless, electronically controlled version of the AEM synchronous generator with integrated AEM voltage regulator (AVR) meets the highest standards in terms of technical parameters, performance, reliability and ease of maintenance. These machines are used worldwide for applications which include the on-board power supply on ships, hydropower plants, cogeneration plants, emergency power systems and the power supply of test facilities.
Products Details
- Shaft height: up to 710
- Protection degree: up to IP 44
- Cooling system: up to IC 81W
- Speed: up to 1,800 rpm
- Insulation class: F and H
Advantages
- high reliability and long service life
- easy to service
- good efficiency performance
- low mass to power ratio
- integrated electronic excitation system
- high voltage stability
- good dynamic response on application of load
- regulator tailored to AEM generators (in-house development and construction)
- delivery in accordance with classifications (GL, DNV, etc.)
Additional Components
In order to adapt the machines to different applications and for monitoring and documentation purposes, the machines can be equipped with the following additional devices:
- brakes
- incremental encoder for speed measurement
- PTC, KTY and PT 100 for thermal monitoring and the protection of motor windings and bearings
- carbon brush monitoring
- anti-condensation heating for fluctuating ambient temperatures
- voltage regulator
- starting resistors
- leakage sensors
- couplings
- slip ring area lighting
