Vesta - Model CGK/CHM -Chamber Kilns

KILN FURNITURE

• Kiln furniture set can be supplied as an optional extra.

• Operating Temperature : 1200°C ~ 1550°C
• Temperature Control : Firing cycles including cooling are programmable with a thermo PLC
• Thermocouple : Type S (PtRh-Pt) with dual element
• Overtemperature Protection : Standard
• Thermal Insulation : Light refractory bricks and/or Ceramic fiber
• Source of Heat : Low emission high velocity burners with silicon carbide combustion tubes,
• spark ignition and continuous flame monitoring system
• Kiln Pressure : Controlled (optional)
• Kiln Atmosphere : Oxidizing/Neutral (standard) - Reducing (optional)
• Truck Movement : Manual by man power (Motor driven truck movement is optional)
• Body Construction : Welded steel structure
• Coating : Thermoset powder coat
• Standard Color : Beige (RAL 7032 W) + Orange (RAL 2004 W) - Other colors on request.
• Connection : Three Phase + Neutral + Earth
