Ouyad - Model FD-E 20kw Series -Wind Turbine

The material of generator, generator shell, HUB use the spraying process, the corrosion resistance is very good, more than 10 years.

Most popular related searches

the generator bearings with fully sealed design. Can be convenient to oil and clean
Life of the generator bearings is more than 303680 hours (25years)
Patent technology ensure high power of generator under low speed ( with the blade design by us, which have large torque under low speed)
with big overload capability, can work 2 hours under 50% overload
class F insulation of generator
track of the highest power of MPPT, ensure the operation under the highest power
Rotary torque output up to 10KNM. high safety coefficient
Rotary torque is fully sealed, life is more than 25 years
The mechanical brake system uses a drum brake, which has a high stability and strong braking force.
The fully sealed design make a good waterproof.
Cabin space is large, with special care entrance, which is convenient to maintain and reduce the maintenance costs.
Data transmission is using RS485 transmission and Modbus communication protocol. Stable transmission and the transmission distance can reach more than 10KM.
the Control system has independent power supply, with guarantee the high stability of the system . (optional)
the generator is using active variable propeller ( active on the wind ), yawing, multiple protection functions, to ensure the safe operation of the generator.
with rotary electromagnetic brake. Ensure that the life of the main components of the wind turbine is up to 20 years .
Spindle brake of the wind turbine generator ensures its safety for any emergency (the brake is optional items)

Features
