HS Dynamic - 5kw-10kw Francis Turbine Generator for Grid and Off-Grid Usage

1. Compact structure,  easy  to install.
2. Reliable operation, easy to control.
3. high efficiency range, usually from 85%-93%, good output.
4. it can be used at different ranges of water flow, even flow changing too much with high efficiency.

• Check left side table, you will know how much power you can get based on different Head and Flow data, if you can not find it in the table, just tell me your project Head and Flow directly.
• Check below Off-grid power and Grid power selection to know what your usage for your power plant.
• Check below hydropower generator selection to know what kind of generator you need for your power plant.
• You still can not sure about hydropower?  Click here to know more
• It’s time to Build your personal home hydro turbine plant. Quote us now!

• Base Seat No.: 423 – 3250;
• Single hydroelectric generator capacity: 5 KW -10,000 KW;
• Efficiency: 89-95%
• Pole number: 4 – 60
• Rotational speed: 250~1500rpm
• Voltage includes two levels: single phase 110v-120v and 220v-240v, three phase 380v-480v and 6300v.
• Insulation level: B and F

• Motor casing protection grade: IP44-IP54
• Cooling method: ICO141
• Rotation speed: 125 rpm – 3000  rpm
• Efficiency: 90%-96%
• No Excitation unit needed
• Bearing: SKF

Using condition:

1. Ambient air temperature: respond to the season change, but not higher than 40?
2. Elevation: less than 1000m
3. Voltage: as contract requirement. The voltage is effected when the speed change.
4. Current: it is related to the motor load and voltage.
5. Connection method: motor principal windings Y connection, separately it is U(A)?V(B)?W(C)
6. Operating procedure: S1 (continuous)
7. Stator winding limited exotherm(electric-resistivity method):less than 80K.
