Kohlbach - Model K13 - Combustion System

Pellet combustion in industry-standard configuration for use with ENplus pellets and industrial pellets and wood chips for greater independence from the fuel market.

Electrical moving grate, primarily for varying pellet qualities or pellet qualities that deviate from the standards.

No arches thus preventing ash deposits and significantly reducing maintenance workload.

Single or multiple auger feed for optimum infeed dosage, even with very fine grain fuel material.

Compact furnace for optimised efficiency and lowest emissions.

Reliable nominal power with all usable fuels and degrees of water content.

Reliable long lifespan of combustion chamber thanks to full refractory lining and grate frame construction being cooled with boiler water and combustion chamber cooling.

Rapid and simple installation thanks to pre-assembled modules.

Ideal for ENplus pellets according to E14961-2 (quality): A1, A2, B (industrial pellets)

Water content (% weight): less than 10

Size (length and diameter mm): lenght from 3.15 to 40, diameter from 6 to 8

Maximum ash content (% weight): 3

Mechanical de-ashing OR automatic ash discharge to reduce operational maintenance workload and thus long run times between maintenance shut-downs, applicable for all boiler systems (water, steam and thermal oil).

Version also available for the mixing of specified agrarian biomass (miscanthus, corncobs, etc.) upon customer request.
