HRS Heat Exchangers Ltd.
HRS - Model SI Series -Double Tubeplate Industrial Heat Exchangers
The HRS SI Series is a multitube shell and tube heat exchanger designed with the added security of a double tubeplate, providing leak detection to avoid cross contamination between the service and product fluids. The HRS SI series is perfect for industrial applications. Using our corrugation technology, heat transfer and efficiency are increased over standard smooth tube heat exchangers. In addition, potential fouling is minimised.
Most popular related searches
industrial heat exchanger
heat exchanger
shell-and-tube heat exchanger
shell and tube heat exchanger
tube heat exchanger
industrial heat
industrial heating
heat exchanger design
heat exchanger tube
heat exchanger water
Typical applications of the HRS SI Series heat exchangers include:
- Chemicals
- River Water
- Oil
Applications related to Double Tubeplate Industrial Heat Exchangers – HRS SI Series
- Environmental
- Food & Beverages
- Pharmaceutical
- Industrial
Standard Materials of Construction:
- Service side: AISI 304/316L stainless steel
- Product side: AISI 316L stainless steel
Other material options available
Standard Connections:
- Service side: Flange
- Product side: Clamp/Flange
All flange & clamp types available
Surface Finish:
- External: Matt
- Internal: Matt
Design code and compliance:
- PD5500, PED 2014/68/EU, ASME
- TR CU 032 & DOSH Compliant
- Corrugated tubes for increased heat transfer
- Bellows are fitted to absorb differential expansion between shell and inner tubes
- Multiple units can be interconnected and mounted in a frame
- Multipass version available
- PD 5500, PED 2014/68/EU, ASME - TR CU 032, DOSH Compliant
