Trigeneration - Combined Heat, Power and Cooling (CHPC)
Trigeneration or combined cooling, heat and power (CCHP), is the process by which some of the heat produced by a cogeneration plant is used to generate chilled water for air conditioning or refrigeration. An absorption chiller is linked to the combined heat and power (CHP) to provide this functionality. Quadgeneration takes this process one step further with the addition of systems to purify carbon dioxide from the engine exhaust. Combined cooling and power (CCP) is where electricity and cooling are utilised alone.
There are a number of benefits to trigeneration including:
- Onsite, high efficiency production of electricity and heat
- Reduced fuel and energy costs
- Lower electrical usage during peak summer demand
- Engine heat can be used to produce steam of hot water for onsite use
- Significant reductions in greenhouse gas emissions
- No harmful chemical pollutants since water is used as the refrigerant
- Beneficial for improving building’s energy efficiency ratings such as Green Star and NABERS in Australia
Absorption based refrigeration technology offers the most established and economic solution for reduced emission, air conditioning systems.
- Operated with heat, utilising relatively inexpensive ‘excess energy’
- Production of electricity that can be fed into the power grid or used to cover the plant’s electricity requirements
- During cold seasons, the heat can be utilised to cover heat requirements
- Absorption chillers have no moving parts, there for there is no wear and maintenance costs are low.
- Absorption system has noiseless operation
- Low operating costs and lifecycle costs
- Using water as a refrigerant replaces the use of ozone damaging substances.
- Approximately 150-170 kW of cold output is required per 1,000m2 of office space
- The term tonnes of refrigeration (TR) is generally used as the unit of cold energy 1 TR (metric) = 3.86 kWh, 1 TR (US) 3.52kWh
- The term coefficient of performance (COP) is used for referring to the efficiency of an absorption chiller. For a hot water chiller, the COP lies between 0.6 – 0.8 and for a double-effect steam chiller between 1.2 – 1.3
- Cold water temperatures down to 4.5°C can be achieved with lithium bromide salt
- Temperatures down to -60°C can be achieved with ammonia
Across the world, there is a new emphasis on projects that combine climate protection and economical primary power generation. Absorption chiller technology represents an optimal solution for a year-round efficient source of cooling and heat, especially when used in conjunction with a gas engine cogeneration plant. More than 500 systems with GE’s Jenbacher gas engines in combination with absorption chillers have been delivered worldwide.
