Nordex - Model N131/3600 -Wind Turbine
FromNordex SE
With the Delta Generation, Nordex customers benefit from the know-how the Nordex Group has gathered in the multi-megawatt range over many years. Mature technical solutions that have proven their worth thousands of times form a sound basis for the generation of the 3 MW class.
Most popular related searches
- Operating data
- Rated power : 3.6 MW
- Cut-in wind speed : 3.0 m/s
- Cut-out wind speed : 25 m/s
- Rotor
- Diameter : 131 m
- Swept area : 13,478 m²
- Operating range rotational speed : 7.5–13.6 rpm
- Rated rotational speed : 11.9 rpm
- Tip speed : 81.6 m / s
- Speed control : Variable via microprocessor
- Overspeed control : Pitch angle
- Gearbox
- Type : 3-stage gearbox (planetary-planetary-spur gear)
- Generator
- Construction : Doubly fed asynchronous generator
- Cooling system : Liquid / air cooling
- Voltage : 660 V
- Grid frequency : 50 / 60 Hz
- Brake system
- Main brake : Aerodynamic brake (pitch)
- Holding brake : Disc brake
- Hub height
- Hub height : up to 134 m, project and site-specific
