Rise Technology srl products

SUNCHECK8 sorts automatically solar cells according to their electrical data, measured by flash testing system. The sorter basically consists of the cell loading unit connected to the measurement system and finally to sorting bins. The testing system, controlled by pc, collects all relevant data according to IEC 1215, EN 61215, UL 1703 allowing different sorting criteria. It is designed to guarantee high performance and flexibility with maximum care of cell handling. In addition every sorting basket is easily movable to tabber&stringer for a quick loading.

GW200A is made of sturdy, painted steel tubes while the inside parts in contact with water and the drying area are completely made of stainless steel. The opening of the upper structure is carried out by four worm screws with four angle transmission powered by a gear motor. Every washing unit has a water collecting tank that is let in again by means of a pump into the nozzle-carrying tubes after being filtered.

GE200A is an automatic station for EVA application over the glass panel. This station corresponds to the first part of panel preparation just before the strings deposit. The system consist of a special film cutting machine which provides the accurate cut of sheet without damaging it, before unloading it on a suitable conveyor belt. At the end of belt starts the glass overlapping during the glass movement along a conveyor positioned below the EVA conveyor. The working area is completely protected by security fences according with the safety rules. Touch-screen panel allows to customize all working parameters in a very easy way. This system represents the best combination of simplicity, integration and reliability, ensuring the necessary accuracy and repeatability of positioning. Low maintenance and remote control for a prompt technical support permit an easy station control.
