Advanced Energy Industries, Inc. products

Advanced Energy`s FCM10K series provides for three phase three wire of AC-DC embedded power requirements. Featuring high build quality with robust screw terminals, long life, and typical full-load efficiency of greater than 96.3%, reaching a peak of 97%, these units are ideal for use in industrial applications. They are backed by a comprehensive set of industrial safety approvals and certificates. Variable-speed "smart fans" draw on software controls developed by Advanced Energy to match fan speed to the unit`s cooling requirement and load current. Slowing the fan not only saves power but also reduces wear, thus extending its life.

Advanced Energy`s FCM30K series provides for a very wide range of AC-DC embedded power requirement. Featuring high build quality with robust screw terminals, long life, and typical full-load efficiency of greater than 95.5%, these units are ideal for use in industrial and medical applications. They are backed by a comprehensive set of industrial and medical safety approvals and certificates. Variable-speed "smart fans" draw on software controls developed by Advanced Energy to match fan speed to the unit`s cooling requirement and load current. Slowing the fan not only saves power but also reduces wear, thus extending its life.

The CSV series bulk front end power AC-DC supply is designed for systems where scalability and density are requirements. With multiple power levels to choose from, this family provides designers with the ability to change the power supply to optimize according to system power consumption.

The DS3000TE series bulk front-end power AC-DC supply maximizes standard C19/C20 AC inlet distribution connectors. It accepts 180-264 VAC input, delivers a main 12 V output, and a 12 V standby output. Operating at 3000 W from 208-264 VAC, it`s an 80 Plus Titanium power supply with over 96% conversion efficiency at 50% load. Compact at 4.15 x 2.78 x 11 inches, it has a power density of 24 W per cubic inch. Six units on a 19-inch rack shelf provide a total of 18 kW. The DTS3000TE series power supplies are ideal for server, networking, telecom, and redundant power applications. With a main 12 V output delivering up to 250 A and staying regulated down to zero load, they`re perfect for feeding downstream DC-DC converters in distributed power architectures (DPA).

The CSU1300AP power supply is housed in a 1U high rack-mount enclosure measuring just 2.89 x 7.28 inches (73.5 x 185.0 mm). This form factor is significantly narrower and shorter than that of similarly rated earlier generation power supplies, freeing up valuable system space. The CSU1300AP power supply is fully digital and compatible with Advanced Energy`s universal PMBus^® graphical user interface, allowing control via an integral I2C interface using the industry-standard PMBus communications protocol. Each power supply generates a main output of 12 VDC for feeding downstream DC-DC converters in systems using distributed power architectures.

Advanced Energy`s Artesyn CSU1300ADC is housed in the standard 1U x 73.5 x 185 mm form factor featuring -48 VDC input voltage. This DC-DC power supply belongs to the CRPS family of products, and matches the mechanical form and fit of Advanced Energy`s AC-DC power supplies. The common form, fit, and function for all products in the family provides a path for power capacity flexibility, future proofing your system designs.

Advanced Energy`s Artesyn CSU2000ADC is housed in the industry standard 1U x 73.5 x 185 mm form factor featuring -48 VDC input voltage. This DC-DC power supply belongs to the CRPS family of products, and matches the mechanical form and fit of Advanced Energy`s AC-DC power supplies. The common form, fit, and function for all products in the family provides a path for power capacity flexibility, future proofing your system designs.

Advanced Energy`s 33 kW ORv3 HPR Power Shelf is a three-phase input AC-DC power shelf that operates from 3-phase AC power with a nominal input range of 347/200 to 480/277 VAC. The power shelf houses six 5.5 kW ORv3 HPR PSUs that operate in parallel to produce a 50V, 660A output.

Advanced Energy`s 5.5  kW ORv3 HPR PSU is a single phase input AC-DC power supply that operates from AC power with a nominal input voltage range of 200 to 277 VAC, 50/60Hz and has an output of 50VDC at 110A.

Advanced Energy’s 3kW ORv3 PSU is a single phase AC-DC power supply that operates from a nominal input range of 200 to 277 VAC 50/60/Hz and outputs 50VDC, 60A. The Open Compute Project (OCP) Open Rack Version 3 (ORv3) compliant power supply has a peak efficiency of 97.5%. A high performance current sharing mode allows the hot swapable PSUs to be paralleled to achieve very high rack power densities. Six PSUs and a controller are easily installed in the 18kW, 1OU ORv3 power shelf and multiple shelves can operate in parallel.
